Detailed information
| CAD | Part No. 1960 N/mm² LHOL | Part No. 1960 N/mm² RHOL | Nominal diam. d mm | Approx. mass | Weight kgs | Min. breaking load 1770 N/mm2 | Min. breaking load 1960 N/mm2 |
|---|---|---|---|---|---|---|---|
|
|
G654241200 |
G654240200 | 20 | 198 | 1,72 | 281 | 311 |
|
|
G654241220 |
G654240220 | 22 | 240 | 2.09 | 340 | 377 |
|
|
G654241240 |
G654240240 | 24 | 285 | 2.48 | 405 | 448 |
|
|
G654241260 |
G654240260 | 26 | 335 | 2.91 | 475 | 526 |
|
|
G654241280 |
G654240280 | 28 | 388 | 3.38 | 551 | 610 |
|
|
G654241300 |
G654240300 | 30 | 446 | 3,88 | 633 | 701 |
|
|
G654241320 |
G654240320 | 32 | 508 | 4.41 | 720 | 797 |
|
|
G654241340 |
G654240340 | 34 | 573 | 5 | 813 | 900 |
|
|
G654241360 |
G654240360 | 36 | 642 | 5.6 | 911 | 1 009 |
|
|
G654241380 |
G654240380 | 38 | 716 | 3.11 | 1 015 | 1 124 |
|
|
G654241400 |
G654240400 | 40 | 793 | 6,89 | 1 125 | 1 245 |
|
|
G654241420 |
G654240420 | 42 | 874 | 7.6 | 1 240 | 1 373 |
|
|
G654241440 |
G654240440 | 44 | 960 | 8,34 | 1 361 | 1 507 |
|
|
G654241460 |
G654240460 | 46 | 1 049 | 9,12 | 1 487 | 1 647 |
|
|
G654241480 |
G654240480 | 48 | 1 142 | 9,93 | 1 619 | 1 793 |
