Shackle (for rope pear socket)

Part no	No.	WLL kg	A	B	C	D	E	F	Weight kgs	MBL kgs
G007815004	4	3000	76	76	24.5	19	30	21	0.9	25000
G007815005	5	4500	84	84	27	21	33	23	1.5	33000
G007815006	6	5000	92	92	29.5	23	35	25	1.7	37500
G007815007	7	7000	100	100	32	25	38	28	2.1	49000
G007815008	8	8000	108	108	34.5	27	41	31	3.1	54000
G007815009	9	9500	116	116	37	29	44	34	3.6	60000
G007815010	10	12000	128	128	40.5	32	48	37	5	75000
G007815011	11	15000	140	140	44	35	53	40	6.2	95000
G007815012	12	17000	152	152	47.5	38	57	43	7.5	110000
G007815013	13	21000	164	164	51	41	62	46	8.9	135000
G007815014	14	26000	176	173	54	44	66	50	11.1	160000
G007815015	15	30000	188	188	58	47	71	52	13.5	175000
G007815017	17	42500	222	222	68	56	84	62	23	260000
