Ball-bearing Lifting Point BLP – UNC thread

Part no	Code	B	C	D	L	L1	X	Y	Z	M inch	Weight kgs
Z102108	BLP-5/16″ -18 UNC	35	55	13	16	112	57	61	Ø42	5/16″	0.56
Z102110	BLP-3/8″ -16 UNC	35	55	13	20	112	57	61	Ø42	3/8″	0.56
Z102112	BLP-1/2″ -13 UNC	35	55	13	24	112	57	61	Ø42	1/2″	0.57
Z102116	BLP-5/8″ -11 UNC	35	55	13	30	112	57	61	Ø42	5/8″	0.6
Z102120	BLP-3/4″ -10 UNC	34	57	17	30	132	75	67	Ø59	3/4″	1.27
Z102121	BLP-7/8″ -9 UNC	34	57	17	30	132	75	67	Ø59	7/8″	1.3
Z102124	BLP-1″-8 UNC	50	70	17	38	145	75	84	Ø59	1″	1.51
Z102130	BLP-1 1/4″-7 UNC	54	96	22	48	202	106	99	Ø74	1 1/4″	3.39
Z102136	BLP-1 1/2″-6 UNC	54	96	22	57	202	106	99	Ø74	1 1/2″	3.59
Z102142	BLP-1 3/4″-5 UNC	70	120	28	67	242	122	127	Ø93	1 3/4″	6.63
Z102148	BLP-2″-4.5 UNC	70	120	28	76	242	122	127	Ø93	2″	7
