Posted on June 21, 2021By hdyer674In Slings & components Grade 8 - ClassicLeave a comment Detailed information CAD Part no Code WLL t For chain size L E F A Weight kgs Z622036 BL-6-8 1.1 6 27 20 9 14 0.093 Z195823 BL-7/8-8 2.0 7, 8 35 25 11 18 0.187 Z208022 BL-10-8 3.2 10 45 32 14 22 0.393 Z217820 BL-13-8 5.4 13 56 40 17 28 0.768 Z208226 BL-16-8 8.2 16 68 50 22 35 1.485 FacebookTwitterLinkedIn
