SPECIFICATIONS

• Motor – 150hp Texp 1800 rpm 480 v 60hz
• Drive – Timing Belt Style
• Positive Drive – 1.5:1 Ratio
• Blower – Jurop pvt 700 Trilobe Blower 2500 cfm 27hg 15 psi
• Requires a 300 amp Breaker to Operate
• Max Vacuum – 27 Inches of Mercury
• Max Pressure – 29 psi
• Classification Class – DIV 1 Group C&D
• Voltage – 480
• Frequency – 60hz
• Full Load AMPS – 137 amps
• Suction Conveyance – 100+ tons per hour
• Discharge Conveyance – 700 gpm
